Dimensions
215×129×68mm(W×D×H)
1.5kg
Specifications
Volume Infused 0.1~ 9999.9 ml, Step by 0.1 ml
Flow Rate 0.1~ 1800 ml/h, Step by 0.1 ml/h
Accuracy ±3%
Purge / Bolus Rate 1 ~ 1800 ml/h, Step by 1ml/h
KVO Rate Flow rate ≥10 ml/h: KVO rate 3 ml/h
Flow rate <10 ml/h: KVO rate 1 ml/h
Flow rate <1 ml/h: KVO rate = Flow rate
Alarm
Occlusion Pressure Three levels: High, Medium, Low
H: 100 kpa ± 30 kpa; M: 60 kpa ± 25 kpa; L: 40 kpa ± 20 kpa
Alarm Battery error,Low battery,Battery exhausted,
Air in line,Occlusion,Door Open,Pause overtime,
VTBI completion,Drop error,Malfunction,A.C. and D.C. Off
Power
Power Adapter A.C. input power 100V~240V 50/60HZ; D.C. output power 15 V/ 2A
Lithium Battery Nominal Voltage: 10.8 V; Device can work over 7 hrs on battery
Infusion Pump Input Power D.C.15V
Power <20VA
Classification
Class II
