G51SP
5MP Gray Scale Medical Display
Technical Specification
|
Model |
G51SP |
|
Size |
20.1" |
|
Gray scale / Tone(Color) |
4096 |
|
Resolution |
2560×2048 |
|
Pixel Pitch |
0.156×0.156 mm |
|
Brightness |
850cd/m2 Typ. |
|
Contrast Ratio |
900:1 Typ. |
|
Viewing Angle |
176° Typ. |
|
Response Time |
30ms Typ. |
|
Dimension |
378(W)×466(H)×90(D) mm 378(W)×498~621(H)×251(D) mm (with base) |
|
Weight |
7.5kg 11.0kg (with base) |
|
Installation Standard |
VESA 100×100 mm |
|
Input Voltage |
DC 12V |
|
Power Consumption |
70W max. |
|
Energy Saving |
EPA, VESA |
|
MTBF |
>50,000 hours |
|
Support Professional Protective Screen |
Application Area
l Digital Mammography
l DR
G51SP has five million pixels (2560×2048) with high resolution, high brightness, high contrast ratio,
and its super wide viewing angles can be widely used in various kinds of medical imaging equipment,
including digital mammary gland machine and the PACS system.
In G51SP whole period of life, its brightness can maintain stability and make DICOM calibration continuously.
G51SP conforms to the requirements of the medical image with high precision. At the same time,
G51SP uses the graphic design and the AR shield. G51SP has the ability of anti-reflective, easy to clean
and disinfect, anti-screen scratches, etc.
