MR Injection System For CT MRI DSA 100ml Zenith C10

1
MOQ
MR Injection System For CT MRI DSA 100ml Zenith C10
Features Gallery Product Description Request A Quote
Features
Specifications
Electrical Requirements: A.c.198~242V, 50/60Hz, 200VA
Flow Rate: 0.1 ML/sec. To 10 ML/sec. In 0.1 ML/sec. Increments
Syringe Capacity: 100ml For Zenith-C10; 200ml For C20
Certification: CE ISO
Modle: C60
Brand: KENID
High Light:

CT MR Injection System

,

100ml Zenith C10 MR Injection System

,

0.1mL/sec MR Injection System

Basic Infomation
Brand Name: KENID
Certification: CE ISO
Model Number: C60
Payment & Shipping Terms
Delivery Time: 5-8DAYS
Payment Terms: T/T, Western Union
Product Description

MR Injection System For CT MRI DSA

Singe CT Injection System Syringes Tubes



Item Description
Electrical Requirements a.c.198~242V, 50/60Hz, 200VA
Operation Interface Selectable in English, French, German and Chinese
Flow Rate 0.1 mL/sec. to 10 mL/sec. in 0.1 mL/sec. increments
Syringe Capacity 100ml for Zenith-C10; 200ml for C20
Volume 0.1 ml to syringe capacity in 0.1 ml increments



Characteristic
Kenid injector is controlled by a computer system. It takes advantage of specialized syringes and other accessories, so the cost of injection is very low. The delivery rate and volume satisfy all the criteria required by enhanced CT scan.
●The highest delivery rate: 9.9ml/s, the lowest delivery rate: 0.1ml/s. The large range of rate from 0.1ml/s to 9.9 ml/s satisfies all of the requirements for any enhanced CT scan. One to four phases injections meet a variety of CT injection’s need.
●Large-size disposable syringe meets various requirements for volume of any enhanced CT scan.
●The highest pressure limit increase the safety of process
●Relay input/output interface connects to different CT scan facilities in the safest manner.
●Small diameter pipe tube reduces the waste of contrast agent, and synonizes the delivery of contrast agent and scan.
●Long-distance control box enables the user to monitor it in either control room or scanning room.


Specification
Flow Rate: 0.1 to 10 ml/sec in 0.1 ml/sec increments
Pressure Limits: Programmable from 50 to 350 psi in 1 psi increments
Injection Capabilities: 1 to 8 phases

MR Injection System For CT MRI DSA 100ml Zenith C10 0
