Name: Portable Digital Color Doppler Ultrasound System S8 Exp
Brand: kenid
SKU: S8 EXP

Portable Digital Color Doppler Ultrasound System S8 Exp

Product Details:

Place of Origin:	CHINA
Brand Name:	kenid
Certification:	CE,ISO
Model Number:	S8 EXP

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Packaging Details:	carton
Delivery Time:	5-8 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Monitor:	15" Medical High Resolution Monitor	Ports:	Two Transducer Ports
HD:	USB 2.0 / Hard Disk 500 G	Battery:	Built-in Battery
DICOM:	DICOM 3.0: Store / C-Store / Worklist / MPPS / Print / SR / Q&R	Accessories:	AC Power Cord (Specify The Standard: European / American / British / Chinese / Japanese / Italian / South African / Brazilian)
High Light:	Medical Monitor Doppler Portable Ultrasound , Portable Doppler Ultrasound System

S8 Exp Portable Digital Color Doppler Ultrasound System

Size and Weight

⚫ Size: approx. 360 mm (W) × 390 mm (H) × 140

mm (D)

⚫ Weight: approx. 9kg (battery included)

Monitor

⚫ 15 inch medical high resolution monitor

⚫ Resolution: 1024 × 768

⚫ Viewing angle: 80° (left and right), 80° (up and

down)

⚫ Up/down angle: 0° to 40°

Control Panel

⚫ User-oriented design

⚫ Backlight design: panel buttons

⚫ Trackball sensitivity: adjustable

⚫ Concise button design

⚫ Rotation angle: 0° to 120°

⚫ TGC: 8 segment sliders

⚫ Standard key panel

Description

⚫ System boot up: approx. ≤ 80 s

⚫ System shut down: approx. ≤15 s

⚫ Frame rate: ≥ 900 fps (e.g. L742 probe)

⚫ Gray map: 256 levels

⚫ Transducer element: up to 256

⚫ Audio: 0 - 100, 101 levels

Hardware:

S8Exp Main Unit

15" Medical High Resolution Monitor

Two Transducer Ports

USB 2.0 / Hard Disk 500 G

Built-in Battery

Adaptor

Software:

B ( 2B & 4B ) Mode

M Mode

Color Doppler Flow Imaging

Power Doppler Imaging / Directional Power Doppler Imaging

Pulse Wave Doppler Imaging

High Pulse Repetition Frequency

Tissue Harmonic Imaging

Pulse Inversion Harmonic Imaging

LGC (Lateral Gain Compensation)

μ-Scan (2D Speckle Reduction Technology)

Multi-beam Technology

Compound Imaging

Trapezoid Imaging

Freehand 3D

Auto NT

Vis-Needle (Needle Visualization Enhancement)

Anatomic M mode

Auto EF

ECG (Software: Must be Configured with ECG Hardware before Delivery)

M-Tuning (One Button Image Optimization)

DICOM 3.0: Store / C-Store / Worklist / MPPS / Print / SR / Q&R

Accessories:

AC Power Cord (Specify the Standard: European / American / British / Chinese / Japanese / Italian / South African / Brazilian)

Ground Lead

Transducers:

Linear Array L741

Convex Array 3C-A
